KS120B Double Braced X Stand

Name: Hercules KS120B Double Braced X Stand
Brand: Hercules
Price: 59 GBP
Availability: InStock

Current£59

Double-braced steel X-stand with the EZ-LOK five-position height system (52–98 cm), 100 kg rating and a 34 cm tier; folds to 103 × 52 × 11 cm.

Manufacturer page ↗

Where to buy:Andertons ↗

Specifications

General

Manufacturer: Hercules
Status: Current
Price: £59

Design

Stand type: X-frame
Bracing: Double
Tiers: 1
Height adjustment: EZ-LOK (5 positions)

Size & capacity

Max load: 100 kg
Min height: 520 mm
Max height: 980 mm
Support depth: 340 mm

Build

Folds for transport: Yes
Material: Steel

Size & weight

Colours: Black
Weight: 5.9 kg
