K-Board Pro 4

Name: Keith McMillen Instruments K-Board Pro 4
Brand: Keith McMillen Instruments
Price: 599 USD
Availability: Discontinued

DiscontinuedReleased 2018

Four-octave MPE controller with traditionally shaped silicone keys that sense pressure, tilt and horizontal position.

Manufacturer page ↗

Specifications

General

Manufacturer: Keith McMillen Instruments
Status: Discontinued
Released: 2018

Keyboard

Keys: 48
Key size: Full
Key action: MPE surface
Aftertouch: Polyphonic
Keybed: KMI Smart Fabric sensor keys

Controls

Pads: 0
Faders: 0
Knobs / encoders: 0
Display: None
Pitch / mod: Surface

Connectivity

USB: USB-B
CV / Gate out: No
Bluetooth MIDI: No
Pedal inputs: Sustain, Expression
USB bus powered: Yes

Features & software

Features: MPE
Bundled software: K-Board Pro 4 Editor

Size & weight

Colours: Black
Dimensions (W × D × H): 830 × 170 × 25 mm
Weight: 1.6 kg
