Mellotron M4000D
CurrentReleased 2010
Markus Resch's digital Mellotron: the sounds come straight from the first-generation master tapes, and the real trick is the wooden, Mellotron-sized keyboard, which senses how far each key is pressed so notes swell in the way tape does against the head. At 17.5 kg it goes on tour far more easily than an M400, and the 8-second note limit is kept on purpose.
Specifications
General
- Manufacturer
- Mellotron
- Status
- Current
- Released
- 2010
Keyboard
- Keys
- 37
- Aftertouch
- Polyphonic (sent over MIDI)
- Keybed
- Hand-built wooden Mellotron-style keys with per-key depth sensing, F to F
Sounds
- Sections
- Sample playback
- Drawbars
- None
- Sound engine
- Digital playback of Mellotron and Chamberlin tapes: 100 sounds built in (Sound Card 01), plus an expansion slot for 100 more on CompactFlash; Mellotron/Chamberlin character modes, motor modulation, tape-rewind emulation
- Organ models
- None
- Polyphony
- 10 notes
Connections
- Outputs
- XLR balanced, 1/4-inch unbalanced, Headphones
- MIDI ports
- DIN in, DIN out, DIN thru
- Pedal inputs
- Volume, Sustain, Expression, Expression
Features
- Features
- 100 Mellotron and Chamberlin sounds from first-generation master tapes, 24-bit uncompressed playback, A/B sound mix, Half-speed playback, Pitch control, Two colour displays, Expansion card slot, Furniture-grade cabinet with hinged lid, Separate A, B and master outputs
Size & weight
- Colours
- White, Black, Walnut, Mahogany
- Dimensions (W × D × H)
- 859 × 501 × 135 mm
- Weight
- 17.5 kg
