Nord Electro 3 HP 73
Discontinued 2013Released 2008
The Electro 3 on a Hammer Action Portable keybed, with extra piano controls (string resonance on/off, four velocity curves) and a delay the waterfall models lack.
Replaced by Electro 4 HP 73
Specifications
General
- Manufacturer
- Nord
- Status
- Discontinued
- Released
- 2008
Keyboard
- Keys
- 73
- Key action
- Hammer-action
- Aftertouch
- None
- Keybed
- Hammer Action Portable
Sounds
- Sections
- Piano, Electric piano, Organ, Sample playback
- Drawbars
- LED (buttons)
- Sound engine
- Nord Piano Library (185 MB) and Nord Sample Library (68 MB), with the Nord C1 organ engine
- Organ models
- B3 tonewheel, Vox Continental, Farfisa (from the Nord C1)
- Polyphony
- Piano 40–60 voices
Connections
- Outputs
- 1/4-inch unbalanced, Headphones
- MIDI ports
- DIN in, DIN out
- Pedal inputs
- Sustain, Expression, Rotor speed
Features
- Features
- LED drawbar buttons rather than physical drawbars, Rotary speaker simulation, Delay effect
Size & weight
- Colours
- Red
- Dimensions (W × D × H)
- 1078 × 344 × 121 mm
- Weight
- 11 kg
