Hammond XK-5
Current
A single-manual Hammond with an in-house waterfall keybed, three physical contacts per key feeding nine virtual ones, a real 12AU7/12AX7 tube preamp and four sets of drawbars. It is also the brain of the XK-5 System and A-3 when a lower manual is added.
Replaces XK-3c
Specifications
General
- Manufacturer
- Hammond
- Status
- Current
Keyboard
- Manuals
- 1
- Keys per manual
- 61
- Key action
- Waterfall
- Keybed
- 73 keys (61 playing keys plus 12 preset keys), Hammond-built square-front waterfall action with three physical and nine virtual contacts
Sound
- Drawbars
- Physical
- Sound engine
- MTW (Modelled Tone Wheel) organ engine
- Organ models
- Hammond MTW modelled tonewheels (A-100, B-3, C-3 and Mellow voicings), Farf and Vx transistor organs, 32-rank pipe organ
- Polyphony
- 61 (manuals), 5 (pedals)
Connections
- Outputs
- 1/4-inch unbalanced, Headphones, Leslie 11-pin
- MIDI ports
- DIN in, DIN out, USB
- Pedal inputs
- Expression, Rotor speed, Footswitch, Pedalboard
Features
- Features
- Four sets of drawbars plus pedal drawbars, Virtual multi-contact keying, 12AU7/12AX7 tube preamp, Modelled matching transformer, Digital Leslie, Reverse-colour preset keys, H-BUS pedalboard connection, OLED display
Size & weight
- Colours
- Red walnut
- Dimensions (W × D × H)
- 1189 × 401 × 119 mm
- Weight
- 15.7 kg
Accessories
Add-ons made for this organ.
Hammond
MS-XK5 Wood Music Stand
Current- Type
- Music rest
- Fits
- Hammond XK-7D, XK-7, XK-5, XK-5 with XLK-5, A-3
—
