Hammond XK-7
Current
The single-manual version of the XK-7D: the same VEM engine, 6-contact long-key waterfall keybed and bass output in an 18.3 kg package. Key click and leakage live on assignable knobs rather than dedicated ones, and there is a MIDI pedal input instead of a second manual.
Specifications
General
- Manufacturer
- Hammond
- Status
- Current
Keyboard
- Manuals
- 1
- Keys per manual
- 61
- Key action
- Waterfall
- Keybed
- 73 keys (61 playing keys plus 12 preset keys), 6L long-key square-front waterfall action with six physical contacts per key
Sound
- Drawbars
- Physical
- Sound engine
- VEM (Virtual Electro-Mechanical) organ engine
- Organ models
- Hammond VEM (Virtual Electro-Mechanical) physical-modelled tonewheels, Vx, Farf and Ace transistor combo organs, 41 pipe ranks (classical and theatre)
- Polyphony
- 61 (tonewheel organ)
Connections
- Outputs
- 1/4-inch unbalanced, Headphones, Leslie 11-pin
- MIDI ports
- DIN in, DIN out, USB
- Pedal inputs
- Expression, Rotor speed, Footswitch, Pedalboard
Features
- Features
- Four sets of drawbars plus pedal drawbars, Six physical contacts per key, AO-28/AO-29 preamp modelling, Digital Leslie (9 cabinets plus PR-40), Separate bass output, Song record to USB, H-BUS pedalboard connection, Colour display
Size & weight
- Colours
- Red walnut
- Dimensions (W × D × H)
- 1184 × 399 × 128 mm
- Weight
- 18.3 kg
Accessories
Add-ons made for this organ.
Hammond
MS-XK5 Wood Music Stand
Current- Type
- Music rest
- Fits
- Hammond XK-7D, XK-7, XK-5, XK-5 with XLK-5, A-3
—
