Hammond XK-7D
Current
The dual-manual XK built as one unit rather than an XK plus add-on lower manual: two 6-contact long-key waterfall manuals over the new VEM tonewheel model, with dedicated key-click and leakage knobs and a modelled AO-28 preamp. 31.3 kg.
Specifications
General
- Manufacturer
- Hammond
- Status
- Current
Keyboard
- Manuals
- 2
- Keys per manual
- 61
- Key action
- Waterfall
- Keybed
- Two 73-key manuals (61 playing keys plus 12 preset keys each), 6L long-key square-front waterfall action with six physical contacts per key
Sound
- Drawbars
- Physical
- Sound engine
- VEM (Virtual Electro-Mechanical) organ engine
- Organ models
- Hammond VEM (Virtual Electro-Mechanical) physical-modelled tonewheels, Vx, Farf and Ace transistor combo organs, 41 pipe ranks (classical and theatre)
- Polyphony
- 61 (tonewheel organ)
Connections
- Outputs
- 1/4-inch unbalanced, Headphones, Leslie 11-pin
- MIDI ports
- DIN in, DIN out, USB
- Pedal inputs
- Expression, Rotor speed, Footswitch, Pedalboard
Features
- Features
- Two 61-note manuals, Four sets of drawbars plus pedal drawbars, Six physical contacts per key, Key click and leakage knobs, AO-28/AO-29 preamp modelling, Digital Leslie (9 cabinets plus PR-40), Separate bass output, Song record to USB, H-BUS pedalboard connection, Colour display
Size & weight
- Colours
- Red walnut
- Dimensions (W × D × H)
- 1186 × 566 × 192 mm
- Weight
- 31.3 kg
