Hammond A-162
Current
Hammond's A-100 for today: a compact console with twin waterfall manuals, a 25-note pedalboard and a 150 W, five-speaker sound system (15-inch woofer) built in, running the VASE III engine. An 11-pin socket is there if you want a real Leslie.
Specifications
General
- Manufacturer
- Hammond
- Status
- Current
Keyboard
- Manuals
- 2
- Keys per manual
- 61
- Key action
- Waterfall
- Keybed
- Two 73-key waterfall manuals (61 playing keys plus 12 reverse-colour preset keys each); 25-note radiating detachable pedalboard
Sound
- Drawbars
- Physical
- Sound engine
- VASE III digital tonewheels
- Organ models
- Hammond VASE III digital tonewheels (B-Type1, B-Type2, Mellow, Brite, Sawtooth voicings)
- Polyphony
- 61
Connections
- Outputs
- 1/4-inch unbalanced, Headphones, Leslie 11-pin
- MIDI ports
- DIN in, DIN out
- Pedal inputs
- Expression, Rotor speed
Features
- Features
- Two 61-note manuals, Four sets of drawbars plus pedal drawbars, 25-note pedalboard included, Built-in 150 W sound system, Digital Leslie, Microphone input
Size & weight
- Colours
- Red walnut
- Dimensions (W × D × H)
- 1194 × 648 × 965 mm
- Weight
- 90.7 kg
